I found this interesting fraction sequence: $$1,\frac{1}{2},\frac{\frac{1}{2}}{\frac{3}{4}}, \frac{\frac{\frac{1}{2}}{\frac{3}{4}}}{\frac{\frac{5}{6}}{\frac{7}{8}}} ... $$
This sequence surprisingly converges to $\frac{\sqrt{2}}{2}$
Can someone provide a proof or an idea for this ?
Here's my work. I took the 5th term of the sequence and reciprocated everything to get a 1 2 3 4 5 6 pattern in the manner shown by the arrows. It repeats itself at the dotted edge with the dotted edge being common to the two recurring units.
Here's the INCORRECT image attached.
edit : I am very sorry for switching 11 and 12. This was a silly error on my part. This then changes the pattern and it becomes more confusing now.
here's the correct pattern for the first five terms:
I have also written the rules I have identified.
maybe someone can help me spot a pattern just like @C Squared did.
And I seem to like the pattern that @Stinking Bishop has spotted. The binary one. Maybe those lines work. But we want a general (probably recursive) formula.
Note- I concluded that it converges to $\frac{\sqrt{2}}{2}$ by anaysing the first 7 terms.
p.s. - And i did it by hand because i don't know programming :(
