Python : Feature Matching + Homography to find Multiple Objects

Question

I'm trying to use OpenCV via Python to find multiple objects in a train image and match it with the key points detected from a query image. For my case, I'm trying to detect the tennis courts in the image provided below. I looked at the online tutorials and could only figure that it can only detect only one object. I thought of inserting a loop in for it to find multiple objects but I failed to do so. Any idea on how to do it?

I used SIFT as ORB does not work that well for my case.

Here's the code and a sample set of images:

import numpy as np
import cv2
from matplotlib import pyplot as plt
MIN_MATCH_COUNT = 10
img1 = cv2.imread('Image 11.jpg',0)          # queryImage
img2 = cv2.imread('Image 5.jpg',0) # trainImage
Initiate SIFT detector
sift = cv2.xfeatures2d.SIFT_create()
find the keypoints and descriptors with SIFT
kp1, des1 = sift.detectAndCompute(img1,None)
kp2, des2 = sift.detectAndCompute(img2,None)
FLANN_INDEX_KDTREE = 1
index_params = dict(algorithm = FLANN_INDEX_KDTREE, trees = 5)
search_params = dict(checks = 50)
flann = cv2.FlannBasedMatcher(index_params, search_params)
matches = flann.knnMatch(des1,des2,k=2)
store all the good matches as per Lowe's ratio test.
good = []
for m,n in matches:
    if m.distance < 0.7n.distance:
        good.append(m)
if len(good)>MIN_MATCH_COUNT:
    src_pts = np.float32([ kp1[m.queryIdx].pt for m in good ]).reshape(-1,1,2)
    dst_pts = np.float32([ kp2[m.trainIdx].pt for m in good ]).reshape(-1,1,2)
    M, mask = cv2.findHomography(src_pts, dst_pts, cv2.RANSAC,5.0)
    matchesMask = mask.ravel().tolist()
    h,w = img1.shape
    pts = np.float32([ [0,0],[0,h-1],[w-1,h-1],[w-1,0] ]).reshape(-1,1,2)
    dst = cv2.perspectiveTransform(pts,M)
    img2 = cv2.polylines(img2,[np.int32(dst)],True,255,3, cv2.LINE_AA)
else:
    print( "Not enough matches are found - {}/{}".format(len(good), MIN_MATCH_COUNT) )
    matchesMask = None
draw_params = dict(matchColor = (0,255,0), # draw matches in green color
                   singlePointColor = None,
                   matchesMask = matchesMask, # draw only inliers
                   flags = 2)
img3 = cv2.drawMatches(img1,kp1,img2,kp2,good,None,*draw_params)
plt.imshow(img3, 'gray'),plt.show()

Train Image :

Query Image :

• I have already posted this question in Stack Overflow but was recommended by @sophros to try posting it here.
